The EP CTL15 Electric Reach Truck is a high-performance, seated-operator forklift engineered for narrow aisle warehousing, high racking systems, and intensive material handling operations. With a 1,500 kg rated load capacity, advanced AC electric drive technology, and excellent maneuverability, the CTL15 delivers efficiency, safety, and long-term reliability in demanding indoor environments.

Efficient Electric Drive with AC Technology

Equipped with a 48V / 560Ah battery and AC electric drive unit, the EP CTL15 ensures smooth acceleration, low energy consumption, and minimal maintenance. The 7.5 kW drive motor (S2 60 min) and 20 kW lift motor (S3 15%) provide powerful traction and fast lifting performance, making this reach truck ideal for high-throughput warehouses and distribution centers.

Strong Load Handling & High Lift Performance

The CTL15 offers a rated capacity of 1,500 kg at a 600 mm load center, ensuring stable handling of standard pallets. With a maximum lift height of 6,500 mm and a mast extended height of 7,695 mm, it is perfectly suited for multi-level racking and vertical storage optimization.

• Sideways reach: 1,300 mm

• Load distance to drive axle: 213

  Fork carriage class: 2A

Compact Design for Narrow Aisle Operations

Designed specifically for confined warehouse spaces, the EP CTL15 features:

• Working aisle width (Ast): 1,740 mm for 1200 × 1200 mm pallets

• Turning radius: 2,185 mm

• Wheelbase: 1,900 mm

Its compact footprint allows operators to navigate tight aisles with precision and confidence.

Operator Comfort & Safety

The seated operator configuration enhances comfort during long shifts, while the overhead guard cabin height of 2,346 mm provides excellent protection. The seat height of 1,235 mm ensures good visibility and ergonomic operation.

Safety is further enhanced by:

• Electromagnetic service brake

• Electromagnetic parking brake

• Stable axle load distribution for both laden and unladen operation

Durable Chassis & Polyurethane Tyres

Built for durability, the CTL15 is fitted with polyurethane tyres that provide excellent grip and low rolling resistance on warehouse floors.

Front tyres: Φ406 × 170 mm

• Rear tyres: Φ380 × 192 mm

• Ground clearance (laden): 80 mm

The forklift has a service weight of 7,020 kg, ensuring stability when lifting at height.

Forks & Load Handling Precision

The EP CTL15 is equipped with robust forks and a versatile carriage system:

• Fork dimensions: 50 × 120 × 1,200 mm

• Fork carriage width: 860 mm

• Adjustable fork spacing: 250–800 mm

This flexibility allows efficient handling of various pallet sizes and load types.

Fast Travel & Smooth Hydraulic Performance

• Travel speed: 10 km/h (laden) / 10.5 km/h (unladen)

• Lifting speed: 0.40 m/s (laden) / 0.47 m/s (unladen)

• Lowering speed: 0.55 m/s (laden) / 0.45 m/s (unladen)

• Traverse speed: 0.18 m/s (laden/unladen)

These speeds help improve productivity while maintaining smooth, controlled load movement.

Key Specifications Summary

• Manufacturer: EP Equipment
• Model: CTL15
• Type: Electric Reach Truck
• Operator Type: Seated
• Rated Capacity: 1,500 kg
• Lift Height: 6,500 mm
• Battery: 48V / 560Ah (250 kg)
• Drive Unit: AC Electric
